This Fast 24V lithium charger is rated at 20 amps and will charge a 24V 50Ah battery in <2.5 hours or a 24V 100 Ah battery in <5 hours.
Available on backorder
|FOR LARGER QUANTITIES CONTACT SALES@DAKOTALITHIUM.COM|
We highly recommend you use a LiFePO4 compatible charger. 24v chargers for lead acid batteries may work, but will decrease performance and lifespan of the battery.
INPUT 100-240 volts, 50/60HZ. OUTPUT: 28.8 volts, 20.0 amps
Anderson SB 50 connections make it easy to connect your charger to the battery. Install the ring terminals using the bolts on your terminals. Bolt black to your black terminal. Red to your red terminal. Do not short circuit. Then connect the charger via the Anderson plug when you need to charge. Red light on the charger will turn on when charging. Light turns green when the battery is full.
Charger will restart or "wake up" a Dakota Lithium BMS that has turned off a battery due to short circuit or excessive amp draw. Simply connect the charger to the battery to initiate a restart.
Charges at a rate of 20 amps. To determine your charging speed take the amp hour rating of your battery and divide by 18. For example, a 36v 63 amp hour battery (Ah) would charge in 3.5 hours.
For most applications a charging time of 3 - 10 hours provides the longest lifespan for your battery. But if you have an application where you need rapid charging Dakota Lithium batteries can be safely charged in up to 1 hour (at a rate of 1C). For example, you could use a 8 amp charger with a 8 Ah battery for a 1 hour charge time. Charging at a 1 hour rate does reduce the lifespan over time. In our laboratory testing we found that the longest lifespan for Dakota Lithium batteries was at a charging speed of 0.3C or less (we recommend that the charger amp rating is 1/3 or less of the battery amp hour rating for longest lifespan).
28.8 volts is recommended for 24V Dakota Lithium (LiFePO4) batteries. This charger charges at 28.8 volts.
Seems to charge fine
Very easy to hook up to the battery and charges very quickly
I purchased this charger to charge my 24v Dakota battery that powers my trolling motor. This charger charges the battery in about two hours. It’s lightening fast and we’ll worth the money spent.
Works well as expected and good support
Have only used the charger once but it worked perfect. I wanted a simple charger that I didn’t have to use my phone to set parameters etc. It would have been a 5 rating if it wasn’t so expensive. Definitely a quality product I would recommend.
fast charge too bad not mainting charger.
Works as it should, no issues.
