A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.
For More Information on SmartSolar MPPT – See Product Manuals
Description
A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.
The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulphated or otherwise damaged.
For More Information on SmartSolar MPPT – See Product Manuals
Technical Specifications
-
All Victron Products Available:
Dakota Lithium is a Victron distributor and sells a curated catalog of recommended items. All Victron products are available to order, contact sales@dakotalithium.com
-
Dimensions (h x w x d):
3.94 × 5.16 × 2.36 in
-
Weight:
1.43 lbs
-
Battery voltage (auto select):
12/24/48 V
-
Rated charge current:
20 A
-
Nominal PV power, 12 V:
290 W
-
Nominal PV power, 24 V:
580 W
-
Nominal PV power, 48 V:
1160 W
-
Max. PV short circuit current:
100 V
-
Charge voltage 'absorption':
14.4 V / 28.8 V / 57.6 V (adj.)
-
Charge voltage 'float':
13.8 V / 27.6 V / 55.2 V (adj.)
-
Charge algorithm:
multi-stage adaptive
-
Operating temperature:
-22°F to 140°F (-30°C to +60°C)
-
Protection:
Output short circuit / Over temperature
-
Data communication port:
VE.Direct (see the data communication white paper on Victron's website)
-
Protection category:
IP43 (electronic components), IP22 (connection area)
-
Safety:
EN/IEC 62109-1, UL 1741, CSA C22.2
